The opening and closing part of the high-pressure gate valve is the gate, and the movement direction of the gate is perpendicular to the fluid direction. The gate valve can only be fully opened and closed, not adjusted and throttled. The movement forms of the valve rod include lifting rod type - valve rod lifting, the hand wheel does not lift, or lifting rotating rod type - the hand wheel rotates and lifts with the valve rod, and the nut is set on the valve body.

什么是高壓閘閥?有哪些特點?

What is high pressure gate valve? What are the characteristics?

(一)高壓閘閥產品特點

（1） Product features of high pressure gate valve

1、采用中法蘭螺栓連接，支管兩端為法蘭連接結構。

1. The middle flange bolt connection is adopted, and the two ends of the branch pipe are flange connection structure.

2、閥座密封面采用鐵基鉻鎳不銹鋼堆焊而成，耐磨、抗擦傷性能好。

2. The sealing surface of the valve seat is made of iron-based chromium nickel stainless steel, with good wear resistance and scratch resistance.

3、閥桿表面經抗蝕性氮化處理，具有良好的抗腐蝕性和抗擦傷性。

3. The surface of the valve stem is subject to corrosion resistance nitriding treatment, which has good corrosion resistance and scratch resistance.

4、閥門的關閉和開啟由裝在閥蓋上的電動裝置來控制。電動裝置分別配有閥門專用電機、減速箱、轉矩控制機構、行程控制機構、現場操作機構，手、電動切換機構。閥門的開關均由行程控制機構調整，調整轉矩限制機構，可以在行程控制機構失靈的情況下，保護閥門。閥門關閉主要通過電動裝置及能夠調整的楔式雙閘板、萬向頂、夾圈等組成，借閥體內導向作升降運動。

4. The closing and opening of the valve are controlled by an electric device installed on the valve cover. The electric device is equipped with special motor for valve, reducer, torque control mechanism, stroke control mechanism, field operation mechanism and manual and electric switching mechanism. The valve switches are adjusted by the travel control mechanism, and the torque limiting mechanism is adjusted to protect the valve in case of failure of the travel control mechanism. The closing of the valve is mainly composed of electric device and adjustable wedge double ram, universal top, clamping ring, etc., and the lifting movement is carried out through the guidance of the valve body.

5、電動裝置除能就地操作外，還可進行遠距離操作。

5. In addition to local operation, the electric device can also be operated remotely.

(二)高壓閘閥結構特點及用途

（2） Structural characteristics and application of high pressure gate valve

1、電動高壓閘閥結構緊湊、設計合理，閥門剛性好，通道流暢，流阻系數小。

1. The electric high-pressure gate valve has compact structure, reasonable design, good valve rigidity, smooth channel and small flow resistance coefficient.

2、高壓電站閘閥密封面采用不銹鋼和硬質合金，使用壽命長。

2. The sealing surface of high-pressure power station gate valve adopts stainless steel and cemented carbide, with long service life.

3、電動高壓閘閥采用柔性石墨填料、密封可靠、操作輕便靈活。

3. The electric high-pressure gate valve adopts flexible graphite packing, with reliable sealing and light and flexible operation.

4、驅動方式分手動、電動、氣動、齒輪傳動，結構型式：彈性楔式單閘板閘閥、剛性楔式單閘板閘閥和雙閘板閘閥。

4. The driving mode is divided into pneumatic, electric, pneumatic and gear transmission, and the structural type is elastic wedge single gate valve, rigid wedge single gate valve and double gate valve.

5、高壓電站閘閥廣泛適用于石油化工、火力發電廠等油品、水蒸汽管路上作接通或截?cái)喙苈分薪橘|(zhì)的啟閉裝置。

5. High pressure power station gate valves are widely used in petrochemical, thermal power plants and other oil and steam pipelines as opening and closing devices to connect or cut off the medium in the pipeline.
